HWT-B350-Z 5MP, Bullet Motor Zoom 2.7 - 13.5mm , Autofocus function, 40m IR, 4 in 1 video output

The Hikvision HWT-B350-Z is a high-quality 5 MP motorized adjustable bullet camera (vari-focal lens) from the HiWatch / Turbo HD series. (coax connection) This camera combines versatile video output, strong night vision capabilities and rugged build quality, making it suitable for indoor and outdoor use. The 4 in 1 video output makes this camera suitable for Turbo HD/TVI, HDCVI ( analog systems).

Specifications:

• Image sensor: 5 MP CMOS

• Maximum resolution: 2560 × 1944 pixels (Full HD 5 MP)

• Lens: Motorized varifocal lens 2.7 mm - 13.5 mm (autofocus)

• Field of view (FOV):

  • Horizontal: ± 95° - 26°

  • Vertical: ± 72° - 20°

  • Diagonal: ± 126° - 33°

• Minimum illumination: 0.01 Lux @ (F1.2, AGC on); 0 Lux with IR on

• Night vision / IR range: Up to ± 40 meters (EXIR / Smart IR technology)

• Signal / video output: 4-in-1 (switchable between HD-TVI, AHD, HDCVI and CVBS)

• Image processing:

  • Day/night (IR-cut filter)

  • Digital WDR (DWDR)

  • 2D DNR (noise reduction)

  • BLC / HLC (backlight and overexposure compensation)

  • AGC (automatic gain)

  • Automatic or manual white balance

  • Adjustable brightness, contrast, sharpness, mirror, etc.

• Shutter speed:

  • PAL: 1/25 s - 1/50,000 s

  • NTSC: 1/30 s - 1/50,000 s

• Protection / housing: IP67 (dust and water resistant)

• Working environment: -40 °C to +60 °C; ≤ 90 % relative humidity (without condensation)

• Power supply: 12 V DC (±15 %) / 24 V AC (±15 %)

• Power consumption: Max. 8.8 W

• Dimensions: 84.5 mm × 92 mm × 255 mm

• Weight: approx. 680 - 705 grams

• Mounting: 3-axis adjustment (pan / tilt / rotation) for flexible positioning
